KHS

Winslow

Frame Alloy 6061 w/custom formed TT, w/replaceable derailleur hanger Rear Shock N/A Fork SR XCT DS, 100mm, Preload Adj Headset Threadless Zero Stack, 1-1/8 Rims Alloy Double Wall, 29x32H Hub, Front Alloy Disc w/CNC Rotor Flange, QR, 100mm Spacing Hub, Rear Alloy Disc w/CNC Rotor Flange, QR, Cassette, 135mm Spacing Tires CST 1435A, 29x2.1 Spokes 14G Black 32X32 Derailleur, Front Shimano FGD-M310, 34.9 Clamp Derailleur, Rear Shimano Acera M360 Shifters Shimano SL-M310 Trigger Chain KMC Z8 Crankset Shimano TY701 42/32/22T, S: 170mm M-XL: 175mm BB Cartridge Bearing Freewheel / Cassette Shimano CS-HG200-8 12-32T, 8-speed Pedals Wellgo resin platform Seatpost KHS Alloy Micro-adjust, 31.6X350mm Saddle KHS Sport Handlebar Alloy Flat Top, 700mm x 5mm, 31.8 Stem KHS Alloy, 7 Degree, 31.8, S: 75mm M-L: 90mm XL: 105mm Grips KHS Sport, Dual Compound Brake Levers Promax XL-91 Brakes Bengal Cable Disc MB606, 160mm rotors Color Green, Red Frame Size S, M, L, XL (XL blue Only)

Zaca

Frame Alloy 6061 w/custom formed TT, w/replaceable derailleur hanger Rear Shock N/A Fork Zoom 565D 29", 80mm Headset Threadless Zero Stack, 1-1/8 Rims Alloy Double Wall, 29x32H Hub, Front Alloy disc QR, 100mm Spacing Hub, Rear Alloy disc QR, 135mm Spacing Tires 29x2.1, 27 TPI Spokes 14G Black 32X32 Derailleur, Front Shimano Tourney TY10, 34.9 Clamp Derailleur, Rear Shimano RD-TX35D Shifters Shimano ST-EF51 Chain KMC Z50 Crankset Shimano FC-TY701, 42/34/24T, 170mm BB Cartridge Bearing Freewheel / Cassette Shimano 14-34T, 7-speed, Mega Range Freewheel Pedals Resin MTB platform w/boron axle Seatpost KHS Alloy, 31.6X300mm Saddle KHS Sport Handlebar Alloy Flat Top, 700mm x 5mm, 31.8 Stem KHS Alloy 4-bolt,7degree, 31.8, S: 75mm M-L: 90mm XL: 105mm Grips KHS Sport Brake Levers Shimano ST-EF51 Brakes Bengal Cable Disc MB606, 160mm rotors Color Matte Blue, Gloss Black Frame Size S, M, L, XL (XL-Black Only)

2015 KHS SixFifty 200

Frame Alloy 6061 w/Custom Formed TT & replaceable der hanger
Rear Shock N/A
Fork SR Suntour XCT, 100mm, Preload Adj
Headset Threadless 1-1/8, Zero Stack
Rims Alloy , Doublewall, 650Bx32H
Hubs (F/R) Alloy disc QR RR: Cassette
Tires CST C1435A, 650Bx2.1
Spokes 14G Black 32X32
Derailleur, Front Shimano Tourney
Derailleur, Rear Shimano RD-TX35
Shifters Shimano ST-EF51
Chain KMC Z50
Crankset Shimano FC-M131, 42/34/24T, 170m
BB Cartridge bearing
Cassette Shimano CS-HG20-7, 12-32, 7-speed
Pedals Resin MTB platform w/boron axle
Seatpost KHS Alloy micro-adjust 31.6x350mm
Saddle KHS Sport
Handlebar ATB 31.8, 30mm rise/680mm, 4 degree
Stem Alloy 4-bolt,7degree, 31.8 S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips KHS Sport
Brake Levers Shimano ST-EF51
Brakes Bengal cable disc MB606, 160mm rotors
Color Men's: Matte Black w/White, Matte Black w/Silver, Ladies: Matte Blackw/Celeste, Pearl w/Orange
Frame Size Men's: S,M,L,XL Ladies: XS,S

2015 KHS 650 200 - Ladies

Frame Alloy 6061 w/Custom Formed TT & replaceable der hanger
Rear Shock N/A
Fork SR Suntour XCT, 100mm, Preload Adj
Headset Threadless 1-1/8, Zero Stack
Rims Alloy , Doublewall, 650Bx32H
Hubs (F/R) Alloy disc QR RR: Cassette
Tires CST C1435A, 650Bx2.1
Spokes 14G Black 32X32
Derailleur, Front Shimano Tourney
Derailleur, Rear Shimano RD-TX35
Shifters Shimano ST-EF51
Chain KMC Z50
Crankset Shimano FC-M131, 42/34/24T, 170m
BB Cartridge bearing
Cassette Shimano CS-HG20-7, 12-32, 7-speed
Pedals Resin MTB platform w/boron axle
Seatpost KHS Alloy micro-adjust 31.6x350mm
Saddle KHS Sport
Handlebar ATB 31.8, 30mm rise/680mm, 4 degree
Stem Alloy 4-bolt,7degree, 31.8 S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips KHS Sport
Brake Levers Shimano ST-EF51
Brakes Bengal cable disc MB606, 160mm rotors
Color Men's: Matte Black w/White, Matte Black w/Silver, Ladies: Matte Blackw/Celeste, Pearl w/Orange
Frame Size Men's: S,M,L,XL Ladies: XS,S

2015 KHS SixFifty 300 - Ladies

Frame 650B Alloy 6061 w/custom formed TT & DT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCM HLO, 100mm, 1-1/8, Hydraulic lock out, Preload Adj
Headset Threadless 1-1/8, Zero Stack
Rims Weinmann XM25, 650B, 32H, Doublewall
Hubs (F/R) Alloy disc QR RR: Cassette
Tires CST C1435A, 650Bx2.1
Spokes 14G 32X32 Black
Derailleur, Front Shimano Altus
Derailleur, Rear Shimano Altus
Shifters Shimano ST-EF51
Chain KMC Z8
Crankset SR XCT 42/32/22
BB Cartridge bearing
Cassette Shimano CS-HG31 11-34T, 8-speed
Pedals Wellgo resin platform
Seatpost KHS Alloy micro-adjust, 31.6X350mm
Saddle KHS Sport
Handlebar Alloy,31.8 690X15mm
Stem KHS Alloy, 7 Degree, 31.8 S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips KHS Sport, Dual Compound
Brake Levers Shimano ST-EF51
Brakes Bengal cable disc MB606, 160mm rotors
Color Men's: Black/ Silver, Silver Ladies: White/ Blue, Matte Red
Frame Size Men's: S,M,L,XL Ladies: XS,S

2015 KHS Alite 40 - Ladies

Frame TIG-welded Hi-Tensile Steel
Rear Shock N/A
Fork Hi-Tensile unicrown
Headset Threadless 1-1/8"
Rims Alloy single wall
Hubs (F/R) Steel RR FW
Tires Mountain 26X1.95
Spokes 14G 36X36
Derailleur, Front Shimano Tourney
Derailleur, Rear Shimano RD-TX35
Shifters Shimano Revo
Chain KMC Z50
Crankset Shimano FC-M131, 48/38/28T, 170m
BB cotterless 108mm
Freewheel / Cassette Shimano 14-34T, 7-speed, Mega Range Freewheel
Pedals Resin ATB
Seatpost KHS Alloy 28.6x350mm
Saddle KHS Sport
Handlebar Steel 30mm rise/640mm, 6 degree
Stem Alloy threadless, 25 degree
Handlebar tape/Grips Kraton for twist
Brake Levers Alloy linear pull 2.5F
Brakes Alloy, linear pull
Color Men's: Black, Sublime Ladies: Flame Red, Matte King Coal
Frame Size Men's Black: 12,15,17,19 Men's Lime: 15,17,19 Ladies: 16

2015 KHS Alite 24

Frame TIG-welded Hi-Tensile Steel
Rear Shock N/A
Fork Hi-Tensile unicrown
Headset Threadless 1-1/8"
Rims Alloy single wall
Hubs (F/R) Steel RR FW
Tires Mountain 26X1.95
Spokes 14G 36X36
Derailleur, Front Shimano Tourney
Derailleur, Rear Shimano RD-TX35
Shifters Shimano Revo
Chain KMC Z50
Crankset Shimano FC-M131, 48/38/28T, 170m
BB cotterless 108mm
Freewheel / Cassette Shimano 14-34T, 7-speed, Mega Range Freewheel
Pedals Resin ATB
Seatpost KHS Alloy 28.6x350mm
Saddle KHS Sport
Handlebar Steel 30mm rise/640mm, 6 degree
Stem Alloy threadless, 25 degree
Handlebar tape/Grips Kraton for twist
Brake Levers Alloy linear pull 2.5F
Brakes Alloy, linear pull
Color Men's: Black, Sublime Ladies: Flame Red, Matte King Coal
Frame Size Men's Black: 12,15,17,19 Men's Lime: 15,17,19 Ladies: 16

Tucson

Frame KHS Full MSD Carbon 29er w/1.5 Taper Headtube, Disc Only, Internal Cable Routing Fork 29" Manitou Marvel Expert, ISO AIR,100mm, Absolute+ Dampening, Ext Rebound Adj & Compression Adj to Lock, 1.5 Taper Alloy Steerer, 15mm Headset FSA Orbit 1.5E, Zero Stack, 1 1/8"~1.5 Rims WTB STP-I19 TCS, Disc, Double Wall, 29x32H, Tubeless Ready Hub, Front Alloy Disc w/CNC Rotor Flange, 15mm Hub, Rear Alloy disc w/CNC Rotor Flange, QR, Cassette, XD Tires Maxxis Ardent Race, 3C Maxx Speed, 3C/TR, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2 Spokes 14G Black w/Alloy Nipples, 32X32 Derailleur, Front Sram GX 2 x 11, Direct Mount S3 Derailleur, Rear Sram GX 2 x 11, 11s Type 2 Shifters Sram GX 2 x 11s Trigger Chain Sram PC-1130 Crankset Sram GX 1000 X-Glide, 2 x 11, 24/36T, BB30, S: 170, M-XL:175 BB Sram PF30 Freewheel / Cassette Sram XG-1150, 10-42T, 11-speed Pedals N/A Seatpost Q2 Carbon, 31.6x350mm Saddle WTB Volt Comp Handlebar Kore XCD-Flat Top, 31.8, 4.8x710mm Stem Kore XCD, Alloy 3D Forged, Threadless 4-bolt, 31.8, S: 80mm, M-L: 90mm, XL:100mm Grips Q2 Lock-on Brake Levers Shimano New M506, Servo Wave Brakes Shimano M506 Hydraulic Disc, 160mm Rotors Color Orange Frame Size S, M, L, XL

Prescott

Frame 29" Full MSD Carbon, 100mm Travel, 1.5 taper, 12x142 Rear Shock RockShox Monarch RT3 Solo Air with 3 Pos. Flood Gate Switch, Rebound adj. Fork 29" Rock Shox Reba RLT 100mm, Solo Air, Motion Control, External Rebound, External Floodgate, Compression Adj to 'Lock', 1.5 Taper, 15Q Headset FSA Orbit C-40-/48CF, N.42/48CF, 1-1/8"~1.5" Integrated, Carbon Cap Rims DT X1900 Spline Wheel Set, 29" Disc, Straight Pull w/ 15mm Ft & 12mm RR Thru-Axle, Tubeless Ready Hub, Front DT X1900 SPLINE, 15mm Hub, Rear DT X1900 Spline, 12mmx142mm Tires Maxxis Ikon 3C Maxx Speed, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2 Spokes DT X1900 Spline Wheelset Derailleur, Front N/A Derailleur, Rear Sram GX 1, 11s X-Horizon, Type 2 Shifters Sram GX 1, 11s Trigger, Right Only Chain SRAM PC-1130 Crankset SRAM GX 1400, OCT Hollow Forged, X-Sync, 2 pc., PF30, 32T, S:170, M-L: 175 BB Sram PF30 Freewheel / Cassette Sram XG-1150, 10-42T, 11-speed Pedals N/A Seatpost Q2 Carbon, 30.9X350mm Saddle WTB Volt Comp Handlebar FSA V-Drive Low Rise, 740x15mm, 31.8 Stem FSA Gossamer, 3-D Forged Alloy, 31.8, S:70mm, M: 90mm, L: 10mm Grips Q2 Lock-on Brake Levers Sram Guide R, Matchmaker X Brakes Sram Guide R Hydraulic Disc, 4 Piston, Tool Free Reach Adj., 160mm Rotors Color Black/Gray Frame Size S, M, L

2015 KHS SF500

Frame 650B Alloy 6061 w/custom formed TT & DT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCM LO, 100mm, 1-1/8, Fixed Hydraulic Rebound + Hydraulic lock out, Preload Adj
Headset Threadless 1-1/8, Zero Stack
Rims Weinmann U28 Disc, 650B, doublewall
Hubs (F/R) Alloy disc QR RR: Cassette
Tires Maxxis Sphinx 650B x 2.0, Folding
Spokes 14G 32X32 Black
Derailleur, Front Shimano Alivio
Derailleur, Rear Shimano Alivio
Shifters Shimano Alivio
Chain KMC X9
Crankset Shimano Alivio, 40/30/22
BB Cartridge bearing
Cassette Shimano CS-HG20 11-34T, 9-speed
Pedals Wellgo resin platform
Seatpost KHS Alloy micro-adjust, 31.6X350mm
Saddle KHS Sport
Handlebar KHS Alloy,31.8 690X15mm
Stem KHS Alloy, 7 Degree, 31.8 S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips KHS Sport, Dual Compound
Brake Levers Shimano BR-M355
Brakes Shimano BR-M355, Hydraulic Disc, 160mm Rotors
Color Men's: Black w/Silver, Coal w/Orange, Ladies: HiHo Silver w/Red, Tarnished Penny w/Pearl White
Frame Size Men's: S, M ,L ,XL, Ladies: XS, S

2015 KHS SF500 - Ladies

Frame 650B Alloy 6061 w/custom formed TT & DT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCM LO, 100mm, 1-1/8, Fixed Hydraulic Rebound + Hydraulic lock out, Preload Adj
Headset Threadless 1-1/8, Zero Stack
Rims Weinmann U28 Disc, 650B, doublewall
Hubs (F/R) Alloy disc QR RR: Cassette
Tires Maxxis Sphinx 650B x 2.0, Folding
Spokes 14G 32X32 Black
Derailleur, Front Shimano Alivio
Derailleur, Rear Shimano Alivio
Shifters Shimano Alivio
Chain KMC X9
Crankset Shimano Alivio, 40/30/22
BB Cartridge bearing
Cassette Shimano CS-HG20 11-34T, 9-speed
Pedals Wellgo resin platform
Seatpost KHS Alloy micro-adjust, 31.6X350mm
Saddle KHS Sport
Handlebar KHS Alloy,31.8 690X15mm
Stem KHS Alloy, 7 Degree, 31.8 S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips KHS Sport, Dual Compound
Brake Levers Shimano BR-M355
Brakes Shimano BR-M355, Hydraulic Disc, 160mm Rotors
Color Men's: Black w/Silver, Coal w/Orange, Ladies: HiHo Silver w/Red, Tarnished Penny w/Pearl White
Frame Size Men's: S, M ,L ,XL, Ladies: XS, S

2015 KHS SF600

Frame 650B Alloy 6061 Double Butted custom formed TT & DT w/replaceable derailleur hanger, 1.5 Taper
Rear Shock N/A
Fork RST First 650B, Air, 100mm, Air Spring, 1.5 Taper, Rebound Adj, Hydraulic lockout, 15mm Thru Axle
Headset FSA Orbit 1.5E Zero Stack, 1 1/8" x 1.5 Taper
Rims Weinmann U28 Disc w/Single Eyelets, 650B, double wall
Hubs (F/R) Alloy disc w/CNC Rotor Flange, QR RR: Cassette
Tires Maxxis Crossmark 650B x 2.1, Folding
Spokes 14G Black w/alloy nipples, 32X32
Derailleur, Front SRAM X5
Derailleur, Rear SRAM X7 Type 2
Shifters SRAM X5 Trigger
Chain KMC X10
Crankset Shimano Alivio, 44/32/22T
BB Shimano ES25 Octalink, Cartridge bearing
Cassette SRAM PG-1020, 11-36T, 10-speed
Pedals Wellgo alloy ATB 1 pc. w/cnc
Seatpost KHS Alloy micro-adjust, 31.6X350mm
Saddle WTB Volt Sport
Handlebar KHS Alloy,31.8 690X15mm
Stem KHS Alloy 3D Forged S:80mm,M:90mm,L:90mm XL:100mm
Handlebar Grips Q2 Lock-on
Brake Levers Shimano BR-M395
Brakes Shimano BR-M395, Hydraulic Disc, 160mm Rotors
Color Men's: Black/Silver Ladies: White w/Blue
Frame Size Men's: S, M, L, XL Ladies: S

2015 KHS SF700

Frame 650B Alloy 6061 Double Butted custom formed TT & DT w/replaceable derailleur hanger, 1.5 Taper
Rear Shock N/A
Fork Manitou Marvel Comp TS AIR,100mm, Absolute+ Dampening, Ext Rebound Adj & Compression Adj to Lock, 1.5 Taper Alloy Steerer, 15mm Axle
Headset FSA Orbit 1.5E Zero Stack, 1 1/8" x 1.5 Taper
Rims Stan’s Rapid 25 Double Wall, 32H, Tubeless Ready
Hubs (F/R) KT S/B Alloy disc w/CNC Rotor Flange, 15mm Thru-axle front
Tires Maxxis Arent Race,, M329RU, 3C/EXO/TR, 27.5 x 2.2, 120 TPI, Folding, Tubeless Ready
Spokes 14G Black w/Alloy Nipples, 32X32
Derailleur, Front n/a
Derailleur, Rear Sram X1, 11s X-Horizon, Type 2
Shifter Sram X1 11s Trigger, Right Only
Chain KMC X11L
Crankset Sram X1 1000 X-Sync, Forged, GXP, 36T
Sram GXPBB Sram GXP
Cassette Sram XG-1180, 10-42T, 11-speed
Pedals n/a
Seatpost KHS Alloy micro-adjust, 31.6X350
Saddle WTB Volt Comp
Handlebar Kore XCD 1 Riser, 720 x 15mm
Stem Kore XCD, 3D Forged, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Shimano BR-M506, Servo Wave
Brakes Shimano BR-M506, Hydraulic Disc, 160mm Rotors
Color Mid Blue/White
Frame Size S,M,L,XL

2015 KHS SF800

Frame KHS 650B Full MSD Carbon Monocoque, 1-1/8-1.5 Taper, Disc Only
Rear Shock N/A
Fork Fox 32 Float 27.5”, CTD O/C, 100mm, Air, Extrnl Rbnd, CTD Low Speed Compression, 1.5 Taper, 15mm Thru Axle
Headset FSA Orbit C-40-CF-ACB, N.42CF, 1-1/8"~1.5" Integrated Carbon Cap
Rims Stan’s Rapid 25 Double Wall, 28H,Tubeless Ready
Hubs (F/R) KT Lightweight S/B Alloy Disc, 15mm, Straight Pull, Cassette Rear
Tires Maxxis Ikon, M319RU, 3C/EXO/TR, 27.5 x 2.2, 120 TPI Folding, 3C/EXO/Tubeless Ready
Spokes 14G/15G Dbl Butted Black Stnls w/Alloy Nipples, 28x28
Derailleur, Front Sram X7 E-Type
Derailleur, Rear Sram X9 Type 2
Shifters Sram X7 Triggers
Chain SRAM PC-1051
Crankset SRAM S1000, 2 pc. PF30, 39x26T
BB Sram PF30
Freewheel / Cassette Sram PG-1050, 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Carbon, 31.6x350mm
Saddle WTB Volt Comp
Handlebar Kore XCD Riser, 710 x 15mm, 31.8
Stem Kore XCD, 3D Forged, 31.8mm S:80mm,M:90mm,L:90mm XL:100mm
Handlebar tape/Grips Q2 Lock-on
Brake Levers Sram Guide R, Matchmaker X
Brakes Sram Guide R Hydraulic Disc, 4 Piston, Tool Free Reach Adj., 160mm Rotors
Color Matte Black/Matte Gray
Frame Size S, M, L, XL

2015 KHS SF900 Team

Frame KHS 650B Full MSD Carbon Monocoque, 1-1/8-1.5 Taper, Disc Only
Rear Shock N/A
Fork Fox 32 Float 27.5", FIT CTD Remote w/Kashima, 100mm, Air, External Rebound, Remote CTD Low Speed Compression, 1.5 Taper, 15mm Thru Axle
Headset FSA Orbit C-40-CF-ACB, N.42CF, 1-1/8"~1.5" Integrated Carbon Cap
Rims DT XR 1501 Spline Wheel SET, 650B Disc, Straight Pull w/15mm Thru-Axle, Tubeless Ready
Hubs (F/R) DT XR 1501 Spline, Wheel set
Tires Maxxis Ikon, M319RU, 3C/EXO/TR, 27.5 x 2.2, 120 TPI Folding, 3C/EXO/Tubeless Ready
Spokes DT XR 1501 Spline, Wheel set
Derailleur, Front N/A
Derailleur, Rear Sram XX 1, 11s X-Horizon, Type 2
Shifters SSram XX 1, 11s Trigger, Right Only
Chain Sram PC-XX1
Crankset Sram XX1, Carbon W/Forged Alloy Spider, PF30, 36T
BB Sram PF30
Cassette Sram XG-1195, 10-42T, 11-speed
Pedals N/A
Seatpost Q2 Team Full Carbon, 27.2x350
Saddle Velo 1557 Ultra Light w/Carbon Base& Ti-Rail
Handlebar Ritchey Low Rise WCS Carbon, 710x15mm
Stem Ritchey 4-Axis 44 WCS, 6D, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Sram Guide RSC, Match Maker X
Brakes Sram Guide RSC Hydraulic Disc, 4 Piston, Tool Free Reach & Pad Contact Adj., 160mm Rotors
Color Team
Frame Size S, M, L, XL

2015 KHS SF2500

Frame 650B 120mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 Rear Axle, w/Replaceable Derailleur Hanger
Rear Shock X-Fusion 02RL, air w/Hydraulic Dampening, Rebound Adj & Lockout
Fork RST First 650B, Air Spring, 120mm, Alloy 1.5 Taper, Rebound Adj, Hydraulic lock out
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims Sun Helix TR25, 32H, Double Wall w/Eyelets, Tubeless Ready
Hubs (F/R) KT S/B Alloy disc w/CNC Rotor Flange, 15mm front, Cassette rear
Tires Maxxis Ardent 27.5 x 2.25, Folding, Tubeless Ready
Spokes 14G Black w/Alloy Nipples, 32X32
Derailleur, Front Sram X5 S3 Direct
Derailleur, Rear Sram X7 type 2
Shifters Sram X5 Trigger
Chain KMC X10 w/missing Link
Crankset KHS 2pc Forged, 38/24, w/Alloy Chainrings
BB PF92
Cassette Sram PG1020 11-36T, 10-speed
Pedals N/A
Alloy Seatpost Alloy micro-adjust, 30.9X350
Saddle WTB Volt Sport
Handlebar Alloy, 700X15 rise
Stem KHS Alloy 3D Forged, 4-bolt,7degree, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Shimano New M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 160mm Rotors
Color Matte Gray/Matte Red
Frame Size S, M, L, XL

2015 KHS SF3500

Frame 650B 120mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 Rear Axle, w/Replaceable Derailleur Hanger
Rear Shock Rock Shox Monarch RT3 HV, Solo Air with 3 Pos. Flood Gate Switch, Rebound adjust
Fork Rock Shox Reba RLT, 120mm, 1-1/8-1.5 Tapered Alloy Steerer, Motion Control, External rebound, Low Speed Compression to ‘Lock’ with External Floodgate, 15mm Through Axle
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims Stan’s Rapid 25, Double Wall, 28H, Tubeless Ready
Hubs (F/R) KT Lightweight S/B Alloy Disc, 15mm front, Cassette, 12 x 142mm, Straight Pull
Tires Maxxis Ardent 27.5 x 2.25, Folding, Tubeless Ready
Spokes 14G Black w/Alloy Nipples, 28X28
Derailleur, Front Shimano SLX FDM675E
Derailleur, Rear Shimano XT, RDM786, Shadow Plus
Shifters Shimano XLS SLM670 w/I-Spec
Chain KMC X10 w/Missing Link
Crankset Shimano FCM625 38/24T
BB Shimano PF92
Cassette Shimano HG5010 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Alloy, 30.9x350
Saddle WTB Volt Comp
Handlebar Kore XCD 1 Riser, 710 x 15mm, 31.8
Stem Kore XCD, 3D Forged, 31.8mm
Handlebar Grips Q2 Lock-on
Brake Levers Shimano New M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 160mm Rotors
Color Matte Black/Matte Silver
Frame Size S, M, L, XL

2015 KHS SF5500

Frame 650B 140mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142mm Rear Axle, w/Replaceable Derailleur Hanger
Rear Shock X-Fusion 02RLX, Air w/hydraulic Dampening, 3 Position Compression Adjust,  Rebound Adj & Lock Out
Fork X-Fusion Velvet RL, 140mm, Alloy 1-1/8-1.5 Tapered Steerer, Hydraulic Dampening, Rebound Adj, Hydraulic Lockout, 15mm
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims Sun Helix TR25, 28H, Double Wall w/Eyelets, Tubeless Ready
Hubs (F/R) KT Lightweight S/B Alloy Disc, 15mm front, Cassette, 12 x 142mm rear, Straight Pull
Tires Maxxis Ardent 27.5 x 2.25, Folding, Tubeless Ready
Spokes 14G/15G Dbl Butted Black Stnls w/Alloy Nipples, 28x28
Derailleur, Front Shimano SLX FDM675E
Derailleur, Rear Shimano SLX RDM675, Shadow Plus
Shifters Shimano SLX SLM670 w/I-Spec
Chain KMC X10 W/Missing Link
Crankset Shimano SLX FCM675 38/24T
BB Shimano PF92
Cassette Shimano CS HG5010, 11-36T, 10-speed
Pedals N/A
Seatpost Kind Shock E-Ten w/Remote, Travel Adjust, 30.9 x 120
Saddle WTB Volt Sport
Handlebar Alloy,31.8 700X15mm
Stem KHS Alloy 3D Forged, 4-bolt,7degree, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Shimano New M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 180/160mm Rotors
Color Matte Blue/Matte Black
Frame Size S, M, L, XL

2015 KHS SF6500

Frame 650B 140mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 Rear Axle, w/Replaceable Derailleur Hanger
Rear Shock Rock Shox Monarch RT3 HV, Solo Air with 3 Position Flood Gate Switch, Rebound adjust
Fork Rock Shox Revelation RLT, 140mm, 1-1/8-1.5 Tapered Alloy Steerer, Motion Control, External Rebound, Low Speed Compression to ‘Lock’ with External Floodgate,15mm Through Axle
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims Sun Charger Expert Wheel set, Tubeless Ready
Hubs (F/R) Sun Charger Expert, Wheel Set, FT:15mm RR: Cassette 12x142mm
Tires Maxxis Ardent 27.5 x 2.25, Folding, Tubeless Ready
Spokes Sun Charger Expert, Wheel set
Derailleur, Front N/A
Derailleur, Rear Sram XO 1, 11s X-Horizon, Type 2
Shifters Sram XO 11s Trigger, Right Only
Chain Sram PC-XX1
Crankset Sram X1 1400 X-Sync, Hollow Forged, PF92, 32T
BB Sram PF 92
Cassette Sram XG-1195, 10-42T, 11-speed
Pedals N/A
Seatpost Kind Shock LEV Integra w/Remote, Travel Adjust, Internal Routing, 30.9 x 335
Saddle WTB Volt Comp
Handlebar Kore Mega, 760 x 20mm, 31.8
Stem Kore Durox 3D Forged, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Hayes Prime Sport
Brakes Hayes Prime Sport, 180mm Ft/160mm RR Rotors
Color Matte Team Red/Matte Black
Frame Size S, M, L, XL

2015 KHS SF7200

Frame FSS 650B 160mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 rear axle, w/replaceable derailleur hanger
Rear Shock Rock Shox Monarch RT3, KHS Tuned, Solo air with 3 Position Flood Gate Switch, Rebound adjust
Fork Rock Shox Pike RCT3, 160mm, Solo Air, 1.5 Taper, 15mm Thru-Axle, External Rebound, Low Speed Compression, 3 Position Compression
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims WTB Frequency
Hubs (F/R) Lightweight S/B Alloy Disc, 15mm Front, Cassette, 12x142mm Rear
Tires Maxxis Ardent, 27.5 X 2.25, 60 tpi Folding
Spokes 14G/15G Dbl Butted Black Stnls w/Alloy Nipples, 28x28
Derailleur, Front Shimano SLX, FDM676
Derailleur, Rear Shimano XT, RDM786, Shadow Plus
Shifters Shimano SLX, SLM670 w/I-Spec
Chain KMC X10 w/Missing Link
Crankset Shimano SLX, FCM675, 38/24T
BB Shimano Outboard Bearing
Cassette Shimano HG5010, 11-36T, 10-speed
Pedals N/A
Seatpost Kind Shock E-Ten w/Remote, Travel Adjust, 31.6 x 385
Saddle WTB Volt Comp
Handlebar Kore Durox, 740mm X 20mm, 31.8
Stem Kore Cubix, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Shimano SLX
Brakes Shimano SLX M675 Hydraulic Disc, 180mm Ft/160mm RR Rotors
Color Matte Black/Green
Frame Size S, M, L, XL

2015 KHS SF7500

Frame FSS 650B 160mm, Alloy 6061 w/Custom Formed Dbl.Butted TT & DT, 1.5 Taper, 12 x 142 rear axle, w/replaceable derailleur hanger
Rear Shock Rock Shox Monarch RT3, KHS Tuned, Solo air with 3 Pos. Flood Gate Switch, Rebound adjust
Fork Rock Shox Pike RCT3, 160mm, Solo Air, 1.5 Taper, 15mm Thru-Axle, External Rebound, Low Speed Compression, 3 Position Compression
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims DT M1700 Spline Wheel Set, 650B Disc, Straight Pull w/ 15mm Thru-Axle Front, 12x142mm Rear, Tubeless Ready
Hubs (F/R) DT M1700 Spline Hubset, 15mm Front, Cassette, 12x142mm Rear
Tires Maxxis High Roller II, 27.5 X 2.3, 60 tpi Folding, 3C/EXO/TR, Tubeless Ready
Spokes DT M1700 Spline, Wheel Set
Derailleur, Front N/A
Derailleur, Rear Sram XO 1, 11s X-Horizon, Type 2
Shifters Sram XO 11s Trigger, Right Only
Chain Sram PC-XX1
Crankset Sram X1 1400 X-Sync, Hollow Forged, GXP, 30T
BB Sram GXP-XR
Cassette Sram XG-1195, 10-42T, 11-speed
Pedals N/A
Seatpost Kind Shock LEV DX w/Remote, Travel Adjust, 31.6 x 385
Saddle WTB Volt Comp
Handlebar Q2 Carbon Riser, 740 x 20mm rise
Stem Kore Repute, 31.8
Handlebar Grips Q2 Lock-on
Brake Levers Sram Guide RSC, Match Maker X
Brakes Sram Guide RSC Hydraulic Disc, 4 Piston, Tool Free Reach & Pad Contact Adjust, 180mm Ft/160mm RR Rotors
Color Matte White/Gray
Frame Size S, M, L, XL

2015 KHS Bajada

Frame 29" AL 6061, Horst bearing linkage, 100mm Travel, 1.5 taper, 142 x 12mm rear axle
Rear Shock X-Fusion E1RL air, hydrulic dampening, ext rebound adj & lock out
Fork RST First 29 Air, 100mm, Hydraulic Dampning, Ext Rebound, Lockout, 1.5 Taper
Headset FSA Orbit C-40-ACB, N.42/ACB, 1-1/8"-1.5" Integrated
Rims Stan’s Rapid 25, Double Wall, 29x32H, Tubeless Ready
Hubs (F/R) Alloy disc w/CNC Rotor Flange, QR RR: Cassette
Tires Maxxis Ikon 3C Maxx Speed, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2
Spokes 14G black 32X32
Derailleur, Front Sram X5 34.9
Derailleur, Rear Sram X7 Type 2
Shifters Sram X5 trigger
Chain KMC X-10 w/Missing Link
Crankset KHS 2pc Forged, 38/24, w/Alloy Chainrings
BB PF92
Cassette Sram PG-1020, 11/36T, 10-speed
Pedals N/A
Seatpost KHS Alloy micro-adjust, 30.9x350mm
Saddle WTB Volt Sport
Handlebar Kore XCD 1 Riser, 720 x 15mm, 31.8mm
Stem Kore XCD, 3D Forged, 31.8mm
Handlebar Grips Q2 Lock-on
Brake Levers Shimano M395
Brakes Shimano M395, 160mm Rotors
Color Matte Silver
Frame Size S, M, L

2015 KHS Flagstaff

Frame 29" AL 6061, Horst bearing linkage, 100mm Travel, 1.5 taper
Rear Shock Rock Shox Monarch RL, Solo Air, Ext Rebound, Lockout
Fork 29” Rock Shox Recon Gold TK Solo Air 100mm, Motion Control, External Rebound, Low Speed Compression to Lock, 1.5 Taper, 15Q
Headset FSA Orbit C-40-ACB, N.42/ACB, 1-1/8"-1.5" Integrated
Rims WTB Speed Disc 19, 29x32H, w/eyelets
Hubs (F/R) Alloy disc w/CNC Rotor Flange, Ft: 15mm, RR: Cassette
Tires Maxxis Ikon 3C Maxx Speed, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2
Spokes 14G black 32X32
Derailleur, Front Shimano SLX
Derailleur, Rear Shimano XT, Shadow Plus
Shifters Shimano SLX
Chain KMC X10 W/Missing Link
Crankset Shimano SLX FC-M675, 2 Pc., 38/24T
BB Shimano PF92
Cassette Shimano Deore, CS-HG62-10, 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Alloy, Micro-adjust, 30.9x350mm
Saddle WTB Volt Comp
Handlebar Truvativ Stylo T10, 680 x 20mm rise
Stem Truvativ Stylo T20, 31.8mm
Handlebar Grips Q2 Lock-on
Brake Levers Shimano New M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 160mm Rotors
Color Matte Red
Frame Size S, M, L

2015 KHS Prescott

Frame 29” MSD Carbon Front w/AL 6061 Horst bearing linkage Rear, 100mm Travel, 1.5 taper, 12x142 rear axle
Rear Shock RockShox Monarch RT3 Solo Air with 3 Pos. Flood Gate Switch, Rebound adjust
Fork 29” Rock Shox Reba RLT 100mm, Solo Air, Motion Control, Extrnal Rebound, External Floodgate, Compression adjust to ‘Lock’, 1.5 Taper, 15Q front axle
Headset FSA Orbit C-40-ACB, N.42/ACB, 1-1/8"~1.5" Integrated
Rims American Classic Terrain 29 Disc, 32H, Wheel Set
Hubs (F/R) American Classic Terrain 29 Disc, 32H, 15mm Thru-axle front, 12mm Thru-axle rear
Tires WTB Nano Race, 29X2.1, 60 TPI, Folding
Spokes American Classic Terrain 29, 32H
Derailleur, Front Shimano SLX, FD-M676D
Derailleur, Rear Shimano XT, RD-M786, Shadow Plus
Shifters Shimano SLX, SL-M670, I-Spec
Chain Shimano SLX
Crankset Shimano SLX, Hollowtech II, 38/24T
BB Shimano PF92
Cassette Shimano Deore CS-HG62-10, 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Carbon, 30.9X350mm
Saddle WTB Volt Comp
Handlebar Truvativ Noir T20, Carbon, 680 x 20mm rise
Stem Truvativ Stylo T20, 31.8mm
Handlebar Grips Q2 Lock-on
Brake Levers Shimano SLX Hydraulic, w/I-Spec
Brakes Shimano SLX Hydraulic Disc, 160mm Rotors
Color White/Black
Frame Size S, M, L

2015 KHS Team 29FS

Frame 29” MSD Carbon Front w/AL 6061 Horst bearing linkage rear, 100mm Travel, 1.5 taper, 12x142mm rear axle
Rear Shock FOX Float CTD w/CTD Remote, Air, Rebound Adj
Fork 29" Fox 32 Float W/CTD Remote, 100mm, Air, Extrnl Rbnd, CTD Low Speed Compression, 1.5 Taper, 15mm Thru-axle
Headset FSA Orbit C-40-ACB, N.42/ACB, 1-1/8"~1.5" Integrated
Rims DT X1600 Spline, 29" Disc, Straight Pull w/ 15mm Thru-Axle
Hubs (F/R) DT X1600 Spline RR: Cassette
Tires WTB Nano 2.1 Race, 29X2.1, 60 TPI, Folding
Spokes DT X1600 Spline
Derailleur, Front N/A
Derailleur, Rear Sram XO 1, 11s X-Horizon, Type 2
Shifters Sram XO 11s Trigger, Right Only
Chain Sram PC-XX1
Crankset Sram X1, hollow forged, PF-GXP, 34T
BB Sram PF-GXP
Cassette Sram XG-1195, 10-42T, 11-speed
Pedals N/A
Seatpost Q2 Team Carbon, 31.6X350mm
Saddle Velo Miles Race
Handlebar Truvativ Noir T20, Carbon, 680x31.8
Stem Truvativ Stylo Team T20, 31.8 S:75mm,M:90mm,L:100mm
Handlebar Grips Q2 Lock-on
Brake Levers Sram Guide RSC, Match Maker X
Brakes Sram Guide RSC Hydraulic Disc, 4 Piston, Tool Free Reach & Pad Contact Adjust, 160mm Rotors
Color Team
Frame Size S, M, L

2015 KHS Zaca

Frame Alloy 6061 w/custom formed TT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCT 29", 100mm Travel, Preload Adj
Headset Threadless Zero Stack, ZS44, 1-1/8
Rims Alloy Double Wall, 29x32H
Hubs (F/R) Alloy disc QR, RR: Cassette
Tires CST Critter, 29x2.1
Spokes 14G Black 32X32
Derailleur, Front Shimano Tourney
Derailleur, Rear Shimano RD-TX35
Shifters Shimano ST-EF51
Chain KMC Z50
Crankset Shimano FC-M171, 42/34/24T, 170m
BB Cartridge bearing
Freewheel / Cassette Shimano CS-HG20-7, 12-32, 7-speed
Pedals Resin MTB platform w/boron axle
Seatpost Alloy micro-adjust, 31.6X300mm
Saddle KHS Sport
Handlebar ATB 31.8, 30mm rise/680mm, 4 degree
Stem KHS Alloy, 7 Degree, 31.8 S:80mm,M:80mm,L:90mm XL:100mm
Handlebar tape/Grips KHS Sport
Brake Levers Shimano ST-EF51
Brakes Bengal cable disc MB606, 160mm rotors
Color Matte Black, Orange
Frame Size S, M, L, XL

2015 KHS Winslow

Frame Alloy 6061 w/custom formed TT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCM LO, 100mm Travel, hydraulic dampening, hydraulic lock out
Headset Threadless Zero Stack, ZS44, 1-1/8
Rims Weinmann XM25, Double Wall, 29x32H
Hubs (F/R) Alloy disc w/CNC Rotor Flange, QR RR: Cassette
Tires CST Critter, 29x2.1
Spokes 14G Black 32X32
Derailleur, Front Shimano Acera M360
Derailleur, Rear Shimano Acera M360
Shifters Shimano TX800 Trigger
Chain KMC Z8
Crankset Shimano TX801 42/32/22T
BB Cartridge bearing
Freewheel / Cassette Shimano CS-HG31 11-34T, 8-speed
Pedals Wellgo resin platform
Seatpost KHS Alloy micro-adjust, 31.6x350mm
Saddle KHS Sport
Handlebar Alloy Flat Riser, 31.8, 700x10mm
Stem KHS Alloy, 7 Degree, 31.8mm
Handlebar tape/Grips KHS Sport, Dual Compound
Brake Levers Alloy lever,alloy bracket, Knee Saver, 2F
Brakes Bengal cable disc MB606, 160mm rotors
Color Matte Blue, Lead Silver
Frame Size S, M, L, XL

2015 KHS Tempe

Frame Alloy 6061 w/custom formed TT & DT, w/replaceable derailleur hanger
Rear Shock N/A
Fork RST First 29 Air, 100mm, Alloy steerer, Magnesium lowers, Hydraulic Damp, External rebound, Lockout, 1.5 Taper, 15Q front axle
Headset Threadless Zero Stack, ZS44, 1-1/8
Rims Weinmann U28, Double Wall w/Single Eyelets, 29x32H
Hubs (F/R) Alloy disc w/CNC Rotor Flange, QR RR: Cassette
Tires Kenda Small Block 8, 29X2.1, 60 TPI
Spokes 14G Black w/alloy nipples, 32X32
Derailleur, Front Sram X5
Derailleur, Rear Sram X7 Type 2
Shifters Sram X5
Chain KMC X10 W/Missing Link
Crankset Sram S1000, 44/33/22T
BB Sram GXP
Cassette Sram PG-1030, 11-36T, 10-speed
Pedals Wellgo alloy ATB 1 pc.
Seatpost Alloy micro-adjust, 31.6X350mm
Saddle WTB Volt Sport
Handlebar Kore XCD Super Flat, 700mm x 10mm, 31.8
Stem Kore XCD, 3D Forged, 31.8mm S:80mm,M:80mm,L:90mm XL:100mm
Handlebar Grips KHS Sport, Dual Compound
Brake Levers Shimano BR-M396
Brakes Shimano BR-M396, Hydraulic Disc, 160mm Rotors
Color Matte Gray
Frame Size S, M, L, XL

2015 KHS Tucson

Frame Alloy 6061 Dbl Butted w/Custom Formed TT & DT, 1.5 Taper, w/Replaceable Derailleur Hanger
Rear Shock N/A
Fork 29” Manitou Marvel Comp TS AIR,100mm, Absolute+Dampening, Ext Rebound Adj & Compression Adj to Lock, 1.5 Taper Alloy Steerer, 15mm
Headset FSA Orbit 1.5E, Zero Stack, 1 1/8”~1.5
Rims Stan’s Rapid 25, Double Wall, 29x32H, Tubeless Ready
Hubs (F/R) KT Alloy Disc w/CNC Rotor Flange, FT: 15mm, RR: Cassette
Tires Maxxis Ikon 3C Maxx Speed W/EXO, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2
Spokes 14G Black w/alloy nipples, 32X32
Derailleur, Front Shimano New Deore
Derailleur, Rear Shimano XT, Shadow Plus
Shifters Shimano New Deore
Chain KMC X10
Crankset Shimano New Deore 2-Pc, 38/24T
BB Shimano Outboard Bearing
 Cassette Shimano Deore CS HG50-10, 11-36T, 10-speed
Pedals Wellgo alloy ATB 1 pc.
Seatpost Ritchey 2-bolt Alloy micro-adjust, 31.6X350mm
Saddle WTB Volt Comp
Handlebar Kore XCD-Super Flat 31.8 x 710mm
Stem Kore XCD
Handlebar Grips Q2 Lock-on
Brake Levers Shimano M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 160mm Rotors
Color Matte White
Frame Size S,M,L, XL

2015 KHS 747 29er

Frame Reynolds 520 CrMo Double Butted,T/T 38.1mm, D/T 40mm, S/T 32.4mm
Rear Shock N/A
Fork 29” Manitou Marvel Comp TS AIR,120mm, Absolute+ Dampening, Ext Rebound Adj & Compression Adj to Lock, 1.5 Taper Alloy Steerer, 15mm dropout
Headset FSA 2 (I/I), Orbit E1.5, Zero Stack, 1-1/8/1.5
Rims Stan’s Rapid 28, Double Wall, 29x36H, Tubeless Ready
Hubs (F/R) KT Alloy Disc w/CNC Rotor Flange, 15mm front, Cassette rear
Tires Maxxis Ikon 3C Maxx Speed, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.35
Spokes 14G Black w/Alloy Nipples, 36X36
Derailleur, Front Shimano Deore FDM616, 34.9
Derailleur, Rear Shimano XT RDM786 Shadow Plus
Shifters Shimano Deore SLM610 I-Spec
Chain KMC X10 w/Missing Link
Crankset KHS 2pc Forged W/Outboard Bearing, 38/24, w/Alloy Chainrings
BB Outboard Bearing
Cassette Shimano Deore CS-HG50-10, 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Alloy Micro-Adjust 29.8x400mm
Saddle WTB Volt Comp
Handlebar Kore XCD 1 Riser, 720 x 15mm
Stem Kore XCD,
Handlebar Grips Q2 Lock-On
Brake Levers Shimano New M506, Servo Wave
Brakes Shimano M506 Hydraulic Disc, 160mm Rotors
Color Matte Black
Frame Size XXL, XXXL

2015 KHS Saguaro

Frame KHS High Modulus Full MSD Carbon 29er w/1.5 Taper Headtube, Disc Only, Internal Cable Routing
Fork 29” Rock Shox Reba RLT 100mm, Solo Air, Motion Control, External Rebound, External Floodgate, Compression Remote Lockout, 1.5 Taper, 15mm Thru-axle
Headset FSA Orbit C-40-CF-ACB, N.42CF, 1-1/8”~1.5” Integrated, Carbon Cap
Rims Stan’s Rapid 25, Double Wall, 29x28H, Tubeless Ready
Hubs (F/R) KT Lightweight S/B Alloy Disc, Straight Pull, 15mm front, Cassette rear
Tires Maxxis Ikon 3C Maxx Speed W/EXO, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2
Spokes 14/15g Black Stainless, w/Alloy Nipples 28x28
Derailleur, Front Sram X7, 34.9
Derailleur, Rear Sram X9 Type 2
Shifters Sram X7 Trigger
Chain Sram PC-1051
Crankset Sram S1000, 38/24T
BB Sram PF30
Cassette Sram PG-1050, 11-36T, 10-speed
Pedals N/A
Seatpost Q2 Carbon, 31.6X350mm
Saddle WTB Volt Comp
Handlebar Ritchey 2X Comp, Flat Riser, 31.8x710mm
Stem Ritchey 4-Axis WTD
Handlebar Grips Q2 Lock-on
Brake Levers Sram Guide R Brakes, Match Maker X
Brakes Sram Guide R Hydraulic Disc, 4-Piston, Tool Free Reach Adj, 160mm Rotors
Color Matte Black/Matte Gray
Frame Size S, M, L, XL

2015 KHS Team 29

Frame KHS High Modulus Full MSD Carbon 29er w/1.5 Taper Headtube, Disc Only, Internal Cable Routing
Fork Fox 32 Float 29”, FIT CTD Remote w/Kashima, 100mm, Air, External Rebound, Remote CTD Low Speed Compression, 1.5 Taper, 15mm Thru-axle
Headset FSA Orbit C-40-CF-ACB, N.42CF, 1-1/8”~1.5” Integrated, Carbon Cap
Rims DT X1700 Spline, 29” Disc, Straight Pull w/ 15mm Thru-Axle, Tubeless Ready, Wheel Set
Hubs (F/R) DT X1700 Spline, Wheel Set, 15mm front, Cassette rear
Tires Maxxis Ikon 3C Maxx Speed W/EXO, 120TPI Folding, Triple Compound, Tubeless Ready, 29X2.2
Spokes DT X1700 Spline, Wheel Set
Derailleur, Front N/A
Derailleur, Rear Sram XO 1, 11s X-Horizon, Type 2
Shifters Sram XO 11s Trigger, Right Only
Chain Sram PC-XX1
Crankset Sram XX1, Carbon W/Forged Alloy Spider, PF30, 34T
BB Sram PF30
Cassette Sram XG-1195, 10-42T, 11-speed
Pedals N/A
Seatpost Q2 Team Carbon, 31.6X350mm
Saddle Velo 1557 Ultra Light w/Carbon Base& Ti-Rail
Handlebar Ritchey 2X Carbon WCS, Flat Riser, 31.8x710
Stem Ritchey 4-Axis 44 Pro, 6D, 31.8 S:75, M:90, L:100, XL:110
Handlebar Grips Q2 Lock-on
Brake Levers Sram XO, Match Maker
Brakes Sram XO, 160mm Rotors
Color Team
Frame Size S, M, L

2015 KHS Aguila

Frame Alloy 6061 w/custom formed TT & DT, w/replaceable derailleur hanger
Rear Shock N/A
Fork SR XCM LO, 100mm, Hydraulic Dampening, Fixed Rebound, w/Hydraulic lock out
Headset Threadless Zero Stack, 1-1/8
Rims Weinmann U28, Double Wall, 29x32H
Hubs (F/R) KT Alloy Disc w/CNC Rotor Flange, QR, Cassette rear
Tires CST Critter, 29x2.1
Spokes 14G Black 32X32
Derailleur, Front Shimano Alivio FD-M4000
Derailleur, Rear Shimano Alivio RD-M4000
Shifters Shimano Alivio SL-M4000
Chain KMC X9 W/Missing Link
Crankset Shimano Alivio FCM4000, Octalink, 40/30/22T, S: 170,M-XL: 175
BB Shimano ES25 Octalink
Cassette Shimano CS-HG200-9 11-34T, 9-speed
Pedals Wellgo Resin Platform
Seatpost Alloy Micro-adjust, 31.6X350
Saddle KHS Sport, Dual Density
Handlebar Alloy Flat Top, 700mm x 5mm rise
Stem KHS Alloy 3D Forged, 4-bolt,7degree, 31.8 S:80mm,M:80mm,L:90mm XL:100mm
Handlebar Grips KHS Sport, Dual Compound
Brake Levers Shimano BR-M395
Brakes Shimano BR-M395, Hydraulic Disc, 160mm Rotors
Color Black
Frame Size S, M, L, XL
Previous

Comments are closed.
